Name: Stormwater - Manhole

Display Field: assettype

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>Stormwater manholes is an inventory based on known construction asbuilt data and field inspections.</SPAN></P></DIV></DIV></DIV>

Service Item Id: 8d618345848b41cd8c928f7c452dc0c8

Copyright Text: Schema provided by ESRI's small stormwater system

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1682248.834235549
YMin: 115157.11856481433
XMax: 1815268.3821723014
YMax: 337493.7536150664
Spatial Reference: 102748  (2285)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: ownedby
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
Default Label:
UniqueValueInfos:
• Value: 1
  Label: Our Agency
  Description: N/A
  Symbol:

Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: true

HasM: true

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: Object ID )
• assetid ( type: esriFieldTypeString, alias: Asset ID, length: 50 )
• assettype ( type: esriFieldTypeSmallInteger, alias: Asset Type , Coded Values: [0: Unknown] , [2: Manhole Type 1] , [3: Manhole Type 2] , ...7 more... )
• installdate ( type: esriFieldTypeDate, alias: Install Date, length: 8 )
• ownedby ( type: esriFieldTypeSmallInteger, alias: Owned By , Coded Values: [1: Our Agency] , [2: Private] , [100: Other] )
• maintby ( type: esriFieldTypeSmallInteger, alias: Maintained By , Coded Values: [1: Our Agency] , [2: Private] , [100: Other] )
• conetype ( type: esriFieldTypeSmallInteger, alias: Cone Type , Coded Values: [0: Unknown] , [1: Straight] , [2: Offset] )
• location ( type: esriFieldTypeSmallInteger, alias: Manhole Location , Coded Values: [0: Unknown] , [1: Main Highway] , [2: Light Highway] , ...11 more... )
• surface ( type: esriFieldTypeSmallInteger, alias: Manhole Surface Type , Coded Values: [0: Unknown] , [1: Asphalt] , [2: Concrete Pavement] , ...4 more... )
• covershape ( type: esriFieldTypeSmallInteger, alias: Cover Shape , Coded Values: [0: Unknown] , [3: Arched (with flat bottom) - A] , [4: Barrel - B] , ...9 more... )
• type ( type: esriFieldTypeSmallInteger, alias: Cover Type , Coded Values: [0: Unknown] , [3: Solid] , [4: Vented/Slotted] , ...4 more... )
• channel ( type: esriFieldTypeSmallInteger, alias: Channel , Coded Values: [0: Unknown] , [1: Yes] , [2: No] )
• bench ( type: esriFieldTypeSmallInteger, alias: Bench , Coded Values: [0: Unknown] , [1: Yes] , [2: No] )
• material ( type: esriFieldTypeSmallInteger, alias: Frame Material , Coded Values: [0: Unknown] , [1: Acrylonitrile Butadiene Styrene - ABS] , [5: Cast Iron - CAS] , ...9 more... )
• wall ( type: esriFieldTypeSmallInteger, alias: Wall , Coded Values: [0: Unknown] , [1: Yes] , [2: No] )
• numsteps ( type: esriFieldTypeSmallInteger, alias: Number of Steps )
• stepmaterial ( type: esriFieldTypeSmallInteger, alias: Step Material , Coded Values: [0: Unknown] , [1: Metal - M] , [2: Plastic - P] , ...2 more... )
• symbolrotation ( type: esriFieldTypeSmallInteger, alias: Symbol Rotation , Range: [0, 359] )
• surfacewater ( type: esriFieldTypeSmallInteger, alias: Receives Surface Water , Coded Values: [0: Unknown] , [1: Yes] , [2: No] )
• exitsystem ( type: esriFieldTypeSmallInteger, alias: Water Existing System , Coded Values: [0: Unknown] , [1: Waterway] , [2: Other System] , ...1 more... )
• rimelev ( type: esriFieldTypeDouble, alias: Rim Elevation )
• invertelev ( type: esriFieldTypeDouble, alias: Invert Elevation )
• depth ( type: esriFieldTypeDouble, alias: Depth )
• highpipeelev ( type: esriFieldTypeDouble, alias: High Pipe Elevation )
• Comments ( type: esriFieldTypeString, alias: Comments, length: 255 )
• lifecyclestatus ( type: esriFieldTypeSmallInteger, alias: Life Cycle Status , Coded Values: [0: Unknown] , [1: Proposed] , [2: Proposed - Approved] , ...4 more... )
• shape ( type: esriFieldTypeGeometry, alias: Shape )
• created_date ( type: esriFieldTypeDate, alias: Created Date, length: 8 )
• created_user ( type: esriFieldTypeString, alias: Created User, length: 255 )
• last_edited_date ( type: esriFieldTypeDate, alias: Last Edited Date, length: 8 )
• last_edited_user ( type: esriFieldTypeString, alias: Last Edited User, length: 255 )
• GlobalID ( type: esriFieldTypeGlobalID, alias: Global ID, length: 38 )
• lastinspection ( type: esriFieldTypeDate, alias: Last Inspection, length: 8 )
• inspectioncycle ( type: esriFieldTypeSmallInteger, alias: Inspection Cycle )

Relationships:

• PWSDE.SDE.ManholeInspection (0) -- Related To: Manhole Inspection (1)

Supported Operations:   Query   Query Attachments   Query Analytic   Query Related Records   Generate Renderer   Return Updates
